6 x 6 x 4 Inches Multi-Hole Fiberglass Enclosure, 4 Cover Screws Lift Off Cover 4 Holes 30 mm
Need holes, custom windows, or digital printing?
6 x 6 x 4 Inches Multi-Hole Fiberglass Enclosure F4PBW
List Price: $138.21
Inches: H: 6 W: 6 D: 4
MM: H: 152 W: 152 D: 102
Availability Code: B
Usually stocked item. “B” items ship within 24 hours of receipt of order if in stock. If not in stock 4 weeks.
|
| Material (Box & Cover) | Hot compression molded fiberglass reinforced polyester (thermoset) |
|---|---|
| Cover Screw Size | #10-24 x 3/4 |
| Cover Screw Material | Recessed captive 304 stainless steel |
| Back Panel Screw Size | #10-32x3/8 |
| Cover Retention | Stainless steel beaded cover retention chain |
| Cover Screw Torque | 20-24 in.-lbs. |
| Gasket Material | Poured polyurethane seamless gasket |
| Enclosure Mounting | Integral mounting flange for ease of mounting |
| Soft Edge Design | Rounded edges, minimal protrusions or exposed pocket areas for assembly of dust and debris |
| Chemical Resistance | Provide Link to Chemical Resistance Charts |
|---|---|
| Flammability Rating | UL94-5V |
| Self Extinguishing | Non-halogenated, non-flame propagating |
| Temperature Range | (-76°F to +274°F) (-60°C to +134°C) |
| UL/cUL File # | E64358 |
| Impact Rating (IK10) | Yes |
| CSA Std. C22.2 File # | LR069014 |
| IEC 60529 Ratings | IP66, IP67, IP68 |
| NFPA No. 101 Flame Spread | Class A (1) |
| Outdoor UV Exposure (UL 746C) | (f1) Rated |
| Plenum Space Rating (UL 2043) | Yes |
| UL 1741 File # | E333478 |
| Custom Colors | Yes |
|---|---|
| Silk Screen / Digital Print | Yes |
| EMI/RFI Shielding | Yes |
| Custom Size Windows | No |
| Custom Holes/Cutouts | Yes |
| CAD : 2D DXF | Download CAD |
|---|---|
| CAD : 2D DWG | Download CAD |
| CAD : 2D PDF | Download CAD |
To download CAD 3D files, please fill out the form below.
